LPG and Natural Gas Espresso Machines

1st coffee.jpg

DualFUEL

Espresso on the go.

The Fracino 1 ,2 and 3 group Contempo and Retro coffee machines are also available as a dual fuel option. With the same great specification as our standard 1 ,2 and 3 group machines, but with the option to use LPG, Butane or electricity, they provide unrivalled flexibility and mobility whilst still retaining high volume output. These machines are ideal for mobile catering units and ‘espresso on the go'.

​

During Gas operation, the control systems and rotary pump, where fitted, require a 240v electricity supply at up to 350w. This low power requirement can be easily provided by a 12v gel battery and 12v-240v Inverter to enable fully ‘off-grid’ mobile operation. A pressurised water supply is required by all models in the range. We recommend the use of the FloJet pump system when the equipment is to be connected to portable water containers.

​

The high powered gas burners for these machines provide the equivalent power of their electric counterparts, ensuring that there will be no loss of steam pressure during busy serving periods. Fracino are proud to claim that their gas machines are the most powerful in the world.

Retro Models

FCL1 LPG / Manual



  • Unique dual spring high pressure lever group, delivering 9bar pressure.



Groups >1

coffee 2.jpg
coffee 4.jpg

FCL3 LPG / Manual



  • Unique dual spring high pressure lever group, delivering 9bar pressure.



Groups >3

coffee 3.jpg

FCL2 LPG / Manual



  • Unique dual spring high pressure lever group, delivering 9bar pressure.



Groups >2

Contempo Models

coffee 5.jpg

CON1E LPG / Electronic



  • Operates on gas & 12v battery or mains electricity.

  • Four accurately pre-programmed coffee measures.



Groups > 1

coffee 6.jpg

CON1E LPG / Semi-Auto



  • Operates on gas & 12v battery or mains electricity.

  • Operated by a push-button switch, so the user can control the amount of coffee being dispensed.



Groups > 1

coffee 7.jpg

CON1E LPG / Electronic



  • Operates on gas & 12v battery or mains electricity.

  • Four accurately pre-programmed coffee measures.



Groups > 2

coffee 8.jpg

CON1E LPG / Electronic



  • Operates on gas & 12v battery or mains electricity.

  • Operated by a push-button switch, so the user can control the amount of coffee being dispensed.



Groups > 2

coffee 9.jpg

CON1E LPG / Electronic



  • Operates on gas & 12v battery or mains electricity.

  • Four accurately pre-programmed coffee measures.



Groups > 3

coffee 10.jpg

CON1E LPG / Electronic



  • Operates on gas & 12v battery or mains electricity.

  • Operated by a push-button switch, so the user can control the amount of coffee being dispensed.



Groups > 3

Retro Key Features.

​

  • Large capacity top quality copper boiler, heated by a multiple looped element or by gas.

  • Pressure controlled by a triple contact pressure switch (electric machine only).

  • Brass-bodied, smooth-action lever group with stainless steel shower plate.

  • Highest powered LPG system in the world provides unrivalled output of coffee, hot water and steam.

  • Case, waste and cup tray are all made from stainless steel 304.

  • Automatic water level system with a probe, electronic control unit and solenoid valve.

  • LPG or Butane fuelled heater system, fitted with electronic ignition and flame failure safety device.

  • Boiler pressure is controlled by a gas pressure valve set at 1.0 bar, with a low flame adjustment which controls the gas burner. Please note: a 37(LPG) / 30(BUTANE) mbar gas pressure regulator must be fitted prior to installation of the machine (dual fuel gas machine only).

Contempo Key Features.

​

  • Top quality copper boiler heated by multiple looped element or by gas.

  • Pressure controlled by a triple contact pressure switch.

  • Automatic water level system with a probe, electronic control unit and solenoid valve.

  • The pressure of water and steam is separately controlled by brass safety valves.

  • Hot water and steam are released by rotating the valve handles on the solid brass valves.

  • Brass bodied group with stainless shower plate, solenoid valve and high pressure pump.

  • Thermosyphonic circulation ensures the group is kept constantly hot for perfect coffee making.

  • Case, waste and cup tray are all made from stainless steel 304.

  • Espresso tray for use with the high group feature, ensuring a perfect espresso.

  • LPG or Butane fuelled heater system, fitted with electronic ignition and flame failure safety device.

  • Boiler pressure is controlled by a gas pressure valve set at 1.0 bar, with a low flame adjustment which controls the gas burner. Please note: a 37(LPG) / 30(BUTANE) mbar gas pressure regulator must be fitted prior to installation of the machine (dual fuel gas machine only).

  • High groups to accommodate large takeaway cups and latte glasses, with clearance of 132mm.

Technical Specifications

Model.              Groups.      Cups Per Hour.            Height (mm).       Width (mm).      Depth (mm).        Weight (kg).         Boiler Capacity.           Gas Rating.           Electric Rating.             Element Rating

FCL1LPG        1            100                     830*               375                500                 35                   7L                         2600 watts.     50watts.                2.7kw

FCL2LPG        2            200                     830*               580                500                 55                   14L                       5500 watts.     50 watts.               2.85kw

FCL3LPG        3            300                     830*               785                500                 75                    20L                      7000 watts.     50 watts.              4kw (20Amp)

CON1ELPG     1        120/200                 575                 375               500                 35                    7L                         2600 watts.     350 watts.             2.7kw

CON1LPG       1        120/200                 575                 375               500                 35                    7L                         2600 watts.     350 watts.             2.7kw

CON2ELPG     2        200/400                 575                 580               500.                55                    14L                       5000 watts.     350 watts.             2.85kw

CON2LPG       2        200/400                 575                 580               500                 55                    14L                       5000 watts.     350 watts.             2.85kw

CON3ELPG     3        360/600                 575                 785               500                 75                    20L                       7000 watts.     350 watts.           4kw (20Amp)

CON3ELPG     3        360/600                 575                 785               500                 75                    20L                       7000 watts.     350 watts.           4kw (20Amp)



* Size from the bottom of the machine to top of the lever.

Images and Technical Details are shown for illustration and guidance only. We reserve the right to modify designs or specifications without prior notice.
